Digital Railway Track Gauge (General Purpose)

Name: Digital Railway Track Gauge (General Purpose)
Brand: Antong

GJ-06

Antong Digital Railway Track Gauge (General Purpose)

EQUIPMENT & APPLICATION

Designed for field operations

Measures track gauge and cant on plain track and turnouts. Also supports check gauge, check rail back-to-back distance, check and wing rail gaps, and flangeway width.

Enquire about this product View brochure page

Confirm configuration, range and operating conditions for your project.

Technical & application details

V91 · Page 8

Track gauge range 1410 to 1470 mm

Cant range -185 to +185 mm

Accuracy class Class 0 (≤350 km/h), Class 1 (≤250 km/h)

Operating temperature -30°C to +55°C

Gauge body Length 1600 mm, Weight Approx. 3.0 kg

Power supply Built-in lithium battery

Battery life ≥6 working days

Data transfer Bluetooth, USB

Standards / metrological references: JJG 219—2015 Verification Regulation of Track Gages for Standard Gauge Railway; TB/T 1924—2008 Track Gages for Standard Gauge Railway

Source: Antong Company & Product Brochure V91. Refer to the original brochure and consult our technical team for configuration and applicability of specifications and standards.
